DDC-810 Digital Spot UV Coater adds value to your print products with an eye catching layer of spot UV embellishment that they can touch and feel.

A compact and affordable solution, the DDC-810 offers printers the capability to enhance their images with a layer of texture and depth. Utilizing ink jet technology together with an ultra violet lamp to instantly cure the UV varnish, the DDC-810 applies a gloss finish to defined areas of the substrate giving them more impact and appeal. A CCD camera - which automatically corrects for shrinkage, stretch and skew – along with unique registration marks ensures the accurate and precise alignment of the spot UV image onto the printed document.

Equipped with Duplo’s widely renowned air suction feed system, the DDC-810 can process up to 21ppm (ledger size) and 36ppm (letter size). The unit features a dust roller, metal hydride lamp, ultrasonic double feed detection, fully automated head cleaning purge, and detection sensors for miss-feeds, ink attached, ink near empty, ink disposal tank full, cover open/closed, jam before and after UV lamp, and feed empty. Extremely easy to set up and operate, the DDC-810 is ideal for short to medium digital and offset print jobs.

Offline foiling with Ucos DC-XII Multi Dry Coater,  One Single Unit Performs 4 applications like Foiling/Lamination/Dry Coating/Image Coating.

 The DC XII delivers a multi-purpose solution for print embellishment with the capability to dry coat, foil, and laminate in a single machine. Compact and easy to use, the DC XII utilizes a ceramic thermal roller and a heat control system to precisely apply the desired film on top of the sheet.

 For gloss dry coating, the DC XII utilizes a specially-formulated film that applies full coverage on a sheet of a paper. When the film runs through the heat roller, the adhesive is melted and applied to sheet.

 Without the need of investing in individual foil stamp dies, the DC XII uses a unique adhesive foil that sticks onto the toner used in most presses.

 The DC XII comes standard with an automatic side-to-side flying knife separator system for precise flush cutting of laminated sheets. It also features a dust removing and de-curling system commonly seen in more expensive laminators.

 4-in-1 solution

 A. Hot Foiling

 B. Lamination

 C. Dry Coating

 D. Image Coating

• Two-piece design for easy film setup and removal
• Automatic air suction feed system
• Handles up to 13" width sheets
• Dust Removal Roller

The fully automated DC-618 Slitter/Cutter/Creaser is Duplo’s compact yet powerful all-in-one finishing solution designed for today’s digital printer. With the ability to process up to 6 slits, 30 cuts and 20 creases in one pass, the DC-618 delivers full-bleed applications up to 23 sheets per minute without the white borders and toner cracking for a clean finish.

Produce an array of on demand applications with ease including 24-up business cards, gate-fold invitations, direct mailers, brochures, book covers, and so much more. Bring your finishing in-house!

The DC-616 offers a variety of options for increased versatility and can be added according to the user's needs. Options include the PC Controller software for easy job setup via a PC, a CCD scanner to read barcodes and registration marks, ultrasonic double feed detection, and a perforation unit. The perforation unit comes with two manually-adjustable perforation tools to perforate along the length of the sheet.
