UltraShield 4220

Very high gloss coating for Ink duct application

UltraShield 4220 is a high performance, very high gloss, versatile UV curing over printing varnish suitable for application through ink duct.

    • Specialty polymer technology;excellent transfer
    • High quality surface additives; excellent rub resistance properties
    • Has good flow property; resulting in an excellent lay
  •

    • Ready to use solution
    • Stir well before use
    • Application via ink duct of an offset printing machine. A maximum of 3-5 gsm isrequired for getting optimum results
    • Storage & Handling: Protect from direct sunlight. Store at moderate temperature below 30oC in dry, well ventilated area. Keep containers tightly closed when not in use.
    • Shelf-life: 6 months from the date of manufacture
    • Packing: 20 kg containers and bulk options
    • Caution: Avoid contact with skin and eyes. The use of hand gloves and safety glasses are recommended.
  • Curing condition

    • Lamp energy:    UV lamp - 80W/cm
    • Machine speed:  20 mts/min

    Technical data

    • Rub resistance: High
    • Viscosity: 1900 – 2100 Cps at 30oC
    • Solids: 98 to 100%
