ADONIS

World's most robust Negative Thermal CtP Plate

Adonis is the most robust thermal digital plate used for high-end long-run printing applications. It is manufactured by TechNova in technical collaboration with Agfa-Gevaert N.V. It is designed for high­ resolution, extra long-runs without baking and unmatched in its UV-ink run-length capability. Adonis is the most preferred thermal plate for long-run and UV ink printing in packaging Et commercial print segments and for "Green" printing using alcohol-free founts.

    • Ideally suited for long-run UV-ink printing without post-baking
    • Fully compatible with alcohol-free founts; enables to "Go Green" without the fear of plate failures
    • Suitable for high quality applications and stochastic screening
    • Fast clean-up properties on the press; minimises start-up waste Et machine downtime
    • Excellent dampening latitude; allows high ink density and low damp levels
    • Accredited for use with all the leading brands of thermal plate-setters Et violet processors with preheat
    • Storage Et Handling:10°C to 25°C; 40% to 60% RH. If the storage temperature differs significantly from plateroom temperature, the plates should be acclimatised in their original package for at least 12 hours before unpacking and processing the plates. Always open the package under recommended safe light.
    • Recommended plateroom : Operating temperatures 23°C (±2°C); 40% to 70% RH. conditions
    • Shelf-life : 24 months (from date of manufacturing) under recommended storage conditions







  • Products specifications
    Attribute nameAttribute value
    Plate TypeThermally exposed, Negative-acting, digital plate for sheet and web offset presses
    CoatingTwo-layer system, infrared sensitive, negative-acting
    Gauge (mm)0.28, 0.30
    Spectral Sensitivity830 nm
    Exposure Energy60 mJ / cm2
    Resolution1%-99% dot resolution at 200 lpi screen; 280 lpi hybrid and FM capable
    Image ColorBlue
    Processing StepsConventional wet processing using recommended violet plate developer
    Replenishment Rate80 - 100 ml/m2 with recommended plate replenisher (depending on usage)
    Run-length8,00,000+ impressions without baking; 1,00,000+ impressions using UV-inks (actual run-length may vary depending on press conditions and ink & paper quality)
    Room IlluminationYellow light (avoid daylight and direct sunlight on plate)
    Machine ProcessingViostar Gold Developer (Ready-to-use) / Violet Universal Developer
    Processor ReplenishmentViostar Gold Replenisher (Ready-to-use) / Violet Universal Developer
    FinishersUnifin/RC 795
    DeletionViostar Delete
    Storage after ProcessingUnifin (for storage up to 7 days); NovaKeepGum (for storage up to 3 months)
    Plate CleanerInstaKleen UV (for UV inks); InstaKleen CtP (for conventional inks)
    Fountain SolutionCompatible with all fountain solutions from TechNova
    Press WashCompatible with all recommended washes from TechNova
    Press CareCompatible with all recommended presscare solutions from TechNova
